Giada MiniPC barebone D610, Intel core i3-10110U (2C/4T), 190x149x26mm, UHD Graphics10, 2x SO-DIMM DDR4, 1x M.2 Storage, 1 x M.2 WiFi 1x MiniPCIe 4G, SIM slot, 5xUSB3.2gen2, 1x RS232, 1x DisplayPort, 1 x HDMI 2.0, 1 x HDMI 1.4, TPM2.0, GBit Lan

Giada MiniPC barebone D610, Intel core i3-10110U (2C/4T), 190x149x26mm, UHD Graphics10, 2x SO-DIMM DDR4, 1x M.2 Storage, 1 x M.2 WiFi 1x MiniPCIe 4G, SIM slot, 5xUSB3.2gen2, 1x RS232, 1x DisplayPort, 1 x HDMI 2.0, 1 x HDMI 1.4, TPM2.0, GBit Lan Giada MiniPC barebone D610, Intel core i3-10110U (2C/4T), 190x149x26mm, UHD Graphics10, 2x SO-DIMM DDR4, 1x M.2 Storage, 1 x M.2 WiFi 1x MiniPCIe 4G, SIM slot, 5xUSB3.2gen2, 1x RS232, 1x DisplayPort, 1 x HDMI 2.0, 1 x HDMI 1.4, TPM2.0, GBit Lan
Product Code:
D610-N1-10110UG4H0G-GIA
Artikelnummer:
00021438
Merk:
Giada

Login om uw prijsinformatie te zien!

Giada D610-N1-10110UG4H0G-GIA
Comet Lake High-end Digital Signage Player.

Belangrijkste eigenschappen
- Intel® Comet Lake Processors
- 1 x DP, 2 x HDMI, Supporting 4K Display
- 2 x SO-DIMM DDR4 Memory, Up to 32GB
- 1 x M-key M.2 (2242/2280) for SSD
- 1 x RJ45, 1 x Mini-PCIe for mSATA/WiFi/3G/4G, 1 x SIM Slot

Specificaties
Processor
CPU: Intel® CoreTM i3-10110U / i5-10210U
Chipset: SoC
BIOS: AMI EFI 64 Mbit

Memory
Type: DDR4-2400MHz
Socket: SO-DIMM
Channel: 2
Size: 32GB

Graphics
GPU: Intel® 10th Gen UHD Graphics
Graphic Engine: DirectX 12, OpenGL 4.5, OpenCL 2.1
Interface: 1 x DP (Max.4096 x 2304 @60Hz), 1 x HDMI (Max.4096 x 2160 @60Hz), 1 x HDMI (Max.4096 x 2160 @30Hz)

Network
Controller: 1 x RTL 8111H Gigabit Ethernet
Interface: 1 x RJ45

I/O
USB: 5 x USB3.2 Gen2 (10 Gbps)
Serial Port: 1 x RS232
Audio: 1 x MIC-IN, 1 x AUDIO-OUT
Wireless: 1 x E-key M.2 (2230) for WiFi/BT
MiniPCIe: 1 x Full-size Mini-PCIe for mSATA/WiFi/3G/4G
SIM Card: 1 x SIM-Slot
TPM: Infineon TPM2.0

JAHC
WatchDog Timer: 0~255 Second Time Out Support
Auto Power On: Power Activated Automatically Start
RTC: Set Up Independently Every day
IR remote Control: Support
Wake On LAN: Remote Wake-up

Storage
Socket 1: 1 x M-key M.2 (2242/2280) for SSD

Operation System Supported
Windows: Windows 10 (64bit)
Linux: Support

Power
Power Type: DC-IN
Power Adapter: 12V/19V

Mechanical
Dimensions: 189.6 x 148.3 x 26 mm
Construction: Metal
Mounting: VESA Mounting JZ183

Environment
Operating Temperature: 0?~40? (32 ?~104?) @ 0.7 m/s Air Flow
Relative Humidity: 95% @ 40? (non-condensing)

Certification
Certification: CE, FCC
Er zijn geen uitgebreide specificaties beschikbaar voor dit product.
